Building Rails, Payment Reconciliation on Nomba Virtual Accounts

The Brief

Every Nigerian product team integrating Nomba virtual accounts ends up rebuilding the same plumbing: provision accounts, verify inbound webhooks, reconcile transfers against expected amounts, handle edge cases, and expose a clean ledger to downstream systems.

I built Rails for the Nomba × DevCareer Hackathon 2026 (Infrastructure track) to solve that once. The demo scenario is school-fee collection: each student gets a dedicated Nomba virtual account, inbound transfers auto-reconcile to the right student, and the school admin pulls a per-student statement from a REST API.

The constraint was real: one week, solo, sandbox credentials that eventually had to work in production, hosted on Render Free with Supabase Postgres and Upstash Redis.

What I Built

Rails is a TypeScript/Fastify API plus a BullMQ worker. Downstream teams authenticate with SHA-256–hashed API keys and integrate in under an hour without rebuilding webhook or reconciliation logic.

Core surface area:

• POST /customers — create students/customers with an expected fee amount stored in Rails (integer kobo, not floats)
• POST /customers/:id/accounts — provision or reuse a Nomba virtual account per customer
• POST /webhooks/nomba — verify Nomba HMAC-SHA256, acknowledge with HTTP 200, queue reconciliation
• GET /customers/:id/transactions — paginated ledger
• GET /customers/:id/statement — filterable statement with totals
• POST /webhook-subscriptions — register downstream URLs for signed transfer.* events
• /docs — OpenAPI/Swagger with Bearer authorization

Reconciliation engine — a pure decision function over five states:

Every state change writes an immutable reconciliation_events row. Outbound webhooks (transfer.matched, transfer.underpaid, etc.) are signed with RAILS_WEBHOOK_SECRET and retried with exponential backoff. Delivery attempts are persisted in outbound_webhook_delivery_log.

workflow-diagram

Nomba

Rails API

BullMQ

Worker

Postgres

Downstream

The happy-path flow:

1. School app calls POST /customers/student-003/accounts → Rails provisions VA via Nomba OAuth
2. Parent sends ₦150 to the student's account number
3. Nomba fires payment_success webhook to Rails
4. Rails verifies signature, returns 200, enqueues reconciliation
5. Worker matches amount to expected fee → matched
6. Rails delivers signed transfer.matched to subscribed downstream URL

Production proof: student-003, live Opay transfer, reconciled to matched in under 3 seconds end-to-end.

Problem 1: I Provisioned Against the Wrong Nomba Endpoint

Early on, virtual account creation failed or returned accounts that never received webhooks. I assumed the parent-account endpoint was enough.

Nomba's sub-account model requires scoping VA creation to the sub-account:

The fix was threefold:

1. Call POST /v1/accounts/virtual/{subAccountId} — not a generic parent endpoint
2. Pass NOMBA_SUB_ACCOUNT_ID from env and require it at boot
3. Send the parent accountId header on authenticated requests (Nomba's OAuth contract)

Lesson: Payment APIs are not CRUD. Sub-account scoping is part of the domain model, not a deployment detail you discover in week two.

Problem 2: Webhooks Never Arrived (Until They Did)

Provisioning worked. Transfers landed on Nomba. Rails showed nothing.

I spent hours replaying signed webhooks manually with scripts/send-demo-nomba-webhook.sh — reconciliation worked perfectly on replay. That told me the bug was upstream delivery, not my state machine.

Root cause: Nomba webhook routing is tied to account hierarchy. Until the sub-account was correctly scoped and the webhook URL registered against the right Nomba environment, inbound events simply never hit /webhooks/nomba.

The debugging workflow I wish I'd had on day one:

Fetch the transaction from Nomba's API, extract transactionId / sessionId / amount, then replay with the signing script. That separated "Nomba didn't send" from "Rails didn't process."

Lesson: When webhooks are the source of truth, build a reconciliation fallback before you need it. A fetch-and-replay script is cheap insurance.

Problem 3: Sandbox vs Production Footguns

Sandbox and production Nomba credentials are not interchangeable. I hit this twice:

• NOMBA_BASE_URL pointing at sandbox while testing live transfers
• Webhook signing keys that differ between environments
• Sandbox VA limits (₦150 cap, 2 accounts per user, expiration) that don't exist in production docs the same way

The fix was explicit env validation with Zod at boot and documenting every secret's source in the README — which key comes from Nomba, which ones you generate yourself:

Lesson: Treat environment boundaries as first-class code. If a variable can be sandbox or production, name it loudly and validate the combination at startup.

Problem 4: Render Free Tier Sleeps; Webhooks Don't Wait

Render free tier sleeps after ~15 minutes of inactivity. Nomba does not queue webhooks indefinitely for a cold server.

Transfers happened. Webhooks fired. Rails was asleep. Ledger empty.

Fix: UptimeRobot pinging GET /health every 5 minutes. /health intentionally does not touch Redis or Postgres — it's a lightweight liveness probe:

Lesson: On free-tier hosting, availability is a feature. Budget for a keep-alive strategy or accept that webhook-driven systems will miss events.

Problem 5: Production Build Broke in CI

Local tsx watch masked problems that only surfaced on Render's npm ci && npm run build.

Two separate failures:

Prisma client not generated in production build. Fix: prisma generate in the build script and a dedicated prisma.config.ts for migration datasource.

Vitest globals leaking into production TypeScript. tsc tried to compile test types into dist/. Fix: separate tsconfig.build.json that excludes tests/.

Lesson: Your deploy build command is the real compile target. Run it locally before every push.

Problem 6: BullMQ Was Burning Redis With Zero Traffic

This was a rookie oversight.

Upstash Free gives 500k Redis commands/month. Within hours of deployment — no users, no webhooks — I was already at thousands of commands. Upstash showed keys like:

bull:rails-reconciliation:stalled-check
bull:rails-outbound-webhooks:stalled-check

/health wasn't the culprit. The start command was:

Audit findings:

• API process created 2 Queue clients; worker process created 2 more (duplicate producers)
• Each Worker maintained blocking Redis connections plus stalled-check timers even with an empty queue
• Estimated 5–8 persistent Redis connections idle at all times

I refactored the job layer (src/jobs/) with three changes:

1. Shared Queue connection in the API process — one Redis client for both queues
2. Worker-only outbound producer — removed the duplicate reconciliation Queue in the worker
3. Tuned idle polling — BULLMQ_STALLED_INTERVAL_MS=120000, BULLMQ_DRAIN_DELAY_MS=30000

I also added a pluggable JOB_PROCESSOR (inline | bullmq) so low-traffic deployments can skip Redis entirely. For production I kept optimized BullMQ:

Lesson: Background job infrastructure has a standing cost. BullMQ is correct at scale; on a free-tier hackathon deploy, idle Workers are a billing incident waiting to happen. Measure Redis commands before you demo, not after Upstash emails you.

Image suggestion: Screenshot your Upstash Data Browser showing the stalled-check keys before optimization, and the command count graph dropping after tuning. That visual lands harder than any architecture paragraph.

Problem 7: A Design Call That Saved the Demo

Nomba virtual accounts support an expectedAmount field. If you set it, Nomba can reject or reverse payments that don't match exactly — which kills your ability to demo underpayment and overpayment.

I deliberately stored expectedAmountKobo in Rails and left Nomba's expectedAmount unset:

All amount comparisons happen in integer kobo. The reconciliation function is pure — 38 unit tests, no database required — which made edge-case demos predictable:

Lesson: In fintech demos, who owns the business rule matters. Rails owns expected amounts; Nomba owns settlement. Don't outsource your demo scenarios to a provider constraint you didn't read.

Security Decisions I Didn't Compromise On

Hackathon speed doesn't mean skipping security on the paths that matter:

Inbound Nomba webhooks — HMAC-SHA256 over a colon-delimited payload, timing-safe comparison, 401 on failure, never queued:

event_type:requestId:userId:walletId:transactionId:type:time:responseCode:nomba-timestamp

API keys — SHA-256 hashed at rest, prefix stored for identification, plaintext returned once at creation.

Outbound webhooks — signed with RAILS_WEBHOOK_SECRET, delivery logged with response body and status for audit.

Idempotency — duplicate detection on nombaTransactionId and nombaSessionId before any ledger write. Provisioning is idempotent per customer: existing active VA is returned, not duplicated.

What I'd Do Differently

Start with the replay script, not the queue. Webhook delivery debugging ate a day that fetch-nomba-va-transactions.mjs would have shortened to an hour.

Question standing infrastructure cost on day one. BullMQ was the right abstraction for "ack fast, process async," but I should have audited idle Redis before deploying the worker alongside the API on a free tier.

Split build and dev TypeScript configs immediately. Don't wait for Render to tell you Vitest globals don't belong in production.

Register keep-alive before the first live transfer. One missed webhook during a demo is worse than five minutes of UptimeRobot setup.

The Result

Rails shipped as a public repo with:

• Working MVP on Render + Supabase + Upstash
• Live production transfer reconciled to matched (student-003, ₦150)
• OpenAPI docs with Swagger Authorize for Bearer API keys
• Operational scripts for webhook replay and Nomba transaction backtrack
• Architecture/security note and a full BullMQ/Redis audit doc

The reconciliation engine, webhook security, and ledger APIs are the product. Everything else — Redis tuning, keep-alive pings, build config fixes — is what it actually takes to make fintech infrastructure work on free-tier hosting, not just compile.

Takeaways

1. Webhook systems need three paths: verify, process, and recover. If you can't replay or backtrack a missed event, you don't have a reconciliation system, you have a hope-based architecture.

2. Payment provider docs are the schema. Sub-account IDs, signature payload field order, and environment-specific base URLs are not configuration trivia. Getting any one wrong looks like your code is broken when the integration contract is.

3. Background workers have idle costs. Queues are not free when empty. Measure Redis commands, tune stalledInterval and drainDelay, and question whether you need a worker process at all at current traffic.

4. Own your business rules locally. Expected amounts, edge-case states, and audit trails belong in your database, not in provider-side constraints you can't override during a demo.

5. Free-tier deploys are integration tests. Sleepy servers, build pipelines that differ from dev, and quota-limited Redis will find every assumption you didn't encode in code. Plan for them like features, not surprises.
